Pytes V16 16kWh 51.2V LFP Battery | 10 Years Warranty | UL 9540 certificated with Sol-Ark and CEC Listed

SKU: S-PytesV16-US

Pytes V16 is a 51.2 V low-voltage battery module with about 16 kWh of usable energy, designed to support home solar systems, backup power, and light commercial energy storage. It combines...

$3,659.00$4,573.00 Save $914.00
Add to Wishlist

visapaypalmasteramerican expressshopify paydiscoverdiners clubapple paygoogle pay
Order in the next [totalHours] hours %M minutes to be processed in 72 hours or less and get it between and
Description

Pytes V16 is a 51.2 V low-voltage battery module with about 16 kWh of usable energy, designed to support home solar systems, backup power, and light commercial energy storage. It combines high capacity with strong discharge power, allowing it to run heavy household loads such as HVAC systems, appliances, and EV chargers.

Pytes V16 – a breakthrough in home and commercial energy storage. Built for those who demand more power, more capacity, and more resilience.

Overview

Battery Type 51.2V LFP
Net Capacity 16kWh
Dimensions(L*W*H) 27.10 × 10.24 × 27.56 inch / 688.4 × 260 × 700.0 mm
Certifications UL 9540 Ed.3 (2023), UL 9540A, UL 1973, UN 38.3
Weight 280lbs
Warranty 10 years



Product Features

  • Enhanced Safety

    Tier 1 automotive-grade 314 Ah cells
    Built-in aerosol fire suppression system
    ESS emergency shutdown function
    Proven and mature BMS protection mechanisms

  • Easy & Flexibl
    Wall-mounted or floor-mounted installation
    Seamless integration with mainstream inverters via closed-loop control
    Remote monitoring and upgrading
    Suitable for indoor or outdoor applications

  • Reliable

    IP66 enclosure
    C4-M corrosion resistance
    Self-heating function for low-temperature operation
    UL 9540 Ed.3 (2023), UL 9540A, UL 1973, UN 38.3

  • Scalable
    Expandable up to 16 units (256 kWh) in parallel without a Pytes Hub

Product Specifications

  • Nominal Voltage: 51.2V
  • Voltage Range: 46.5~56.8V
  • Nominal Capacity: 314Ah
  • Nominal Energy: 16kWh
  • Recommended Charge Current: 125A (6.4kW)
  • Recommended Discharge Current: 150A (7.68kW)
  • Maximum Discharge Current: 200A (10.24kW)
  • Cycle Life: 8000cycle
  • Ingress Protection Ratings: IP66
  • Communication Protocol: RS485 / CAN / WIFI / Dry Contact
  • Fire safety: Aerosol fire suppression module integrated

Shipping and Packaging

  • The battery can only ship via freight truck

DOWNLOADS
Datasheet:
Pytes_V16_LFP_Specs.pdf

User Manual & Quick Guide
Pytes_V16_LFP_User Manual.pdf
V16_V10_Selection_Guide.pdf

Configuration
Pytes_V16_LFP_Configuration_with_Deye.pdf
Pytes_V16_LFP_Configuration_with_ED4.pdf

ABOUT Pytes
PYTES, a national high-tech enterprise founded in 2004, focuses on Lithium-ion battery solutions for e-bikes, 3C products, vacuum cleaners, and energy storage systems, etc. Headquartered in Shanghai, PYTES has been expanding globally, setting up three production bases in Shanghai (China), Shandong (China), and Vietnam, and two marketing & service centers in Europe and North America. PYTES is strong in R&D, with advanced laboratories certified by TUV, DEKRA, SGS & BV, etc.
