Sigen LoadHub | Split-Phase | 120/240V 200A | Used With Sigenergy Home
- 5 double-pole controllable loads
- 0 ms load-side disruption
- Supports generator, heat pump or other controllable loads
- Supports both whole-home & partial-home backup
- Uninterrupted power supply through PV+ESS/grid/generator
See the specs
The Sigen LoadHub, when used with Sigenergy Home, provides intelligent energy management and monitoring. It automatically detects outages and offers seamless transition to backup power. You can track energy usage and control energy flow all from the mySigen App.
Product Overview
| Grid Connection | |
| Max. AC main circuit breaker rated current | 200 A |
| Nominal AC output voltage | 120 / 240 V |
| AC Output to Main Distribution Panel | |
| Overvoltage category | III |
| PG Controller Connection | |
| Max. no. of connection | 2 |
| Max. AC cuicirt breaker rated current | 60 A |
| Max. AC nominal power per inverter connection | 14.4 kW |
| Smart Load Port Connection | |
| Max. no. of connection | 5 |
| Max. continuous input/output current | 80A |
| Warranty | 10 Years |
Key Features
-
Light & Strong. Designed to last.
Compared to galvanized steel that is widely used in the industry, Sigen LoadHub has a full Aluminum structure, reducing total weight by over 20 lbs. Anti-rust, corrosion-resistant, and super durable. It not only features a sleek, modern design, but it also impresses with practical functionality.
-
More Controllable Loads. More backup choices.
PointGuard LoadHub is capable of connecting up to two Sigen Home systems at once. There are six double-pole (or 12 single-pole) controllable breaker positions reserved for large loads such as pool pumps or central air conditioners, including one position for a generator. Select and prioritize what you want to backup. Monitor and control your home energy usage. -
Backup Your Way. Uninterruptible moments.
Whether for whole home or partial home backup, the Sigen LoadHub gives you ultimate peace of mind. When outages occur, It is capable of switching to backup power in an instant. That means you can enjoy uninterrupted electricity supply 24/7 from a mix of power sources such as solar, grid, or generator.
Product Specifications
- 5 double-pole controllable loads
- 0 ms load-side disruption
- Supports generator, heat pump or other controllable loads
- Supports both whole-home & partial-home backup
- 350 ms reverse power flow protection of grid & generator
- Uninterrupted power supply through PV+ESS/grid/generator
General Data
- Dimenstions(W/H/D): 21*32*7 in/532*814*180 mm
- Weight: 60 lbs/27 kg
- Cooling: Natural convection
- Enclosure type: Type 3R
- Communications: Fast Ethernat (FE), RS485, dry contact
Shipping and Packaging
- The battery can only ship via freight truck
Download
HUB
Datasheet_-_Sigen_LoadHub_US.pdf
Sigen_LoadHub_Installation_Guide
-01-Sigen_LoadHub_Important_Notice_EN.pdf
-02-Sigen_LoadHub_Installation_Guide_EN.pdf
-03-Sigen_LoadHub_Alarm_list_EN.pdf
APP
